| model | fabrikskode | nominel spænding kv |
system nominelt spænding kv |
svigtende belastning er ikke mindre end | krybning afstand: mm |
diagram - Nej, det er ikke rigtigt. |
skur nummer max./min |
hovedmål (mm) | sammensat tilstand af komponenter | vægt kg |
||||||
| bøje kn |
torsion kn.m |
totalhøjde h |
- Max. - Hvad? skur diameter d |
øverste installationshul | nederste installationshul | |||||||||||
| d ₁ | d ₁ | d ₂ | d ₂ | |||||||||||||
| zcw1-252/n2,5l-3 | 229277 | 252 | 220 | 2.5 | 6300 | 8 | 30/24 | 2400 | 240 | 127 | 4-m16 | 127 | 4-m16 | 226236+ 226237 |
161 | |
| zcw1.1-252/n4 | 229223 | 4 | 5500 | 4 | 26/24 | 2300 | 205 | 180 | 4-Φ13 | 180 | 4-Φ13 | 22643+ 22643 |
95 | |||
| zcw1.2-252/n4-3 | 22987 | 4 | 6300 | 4 | 26/26 | 2300 | 220 | 210 | 4-Φ18 | 210 | 4-Φ18 | 22667+ 22667 |
95 | |||
| zsxw1-252/6-3 | 229259 | 6 | 6 | 6300 | 7 | 30/28 | 2370 | 265 | 140 | 4-m12 | 250 | 4-Φ18 | 227293+ 227295 |
202 | ||
| zsw1-252/6-3 | 229280a | 6 | 3 | 6300 | 5 | 28/28 | 2300 | 250 | 127 | 4-m16 | 225 | 4-Φ18 | 227318a+ 227319a |
160 | ||
| zsw1.1-252/6-3 | 229263 | 6 | 6 | 6300 | 4 | 31/29 | 2360 | 265 | 190 | 4-Φ14 | 270 | 4-Φ18 | 227285+ 227288 |
199 | ||
| zsw1.2-252/6-3 | 229264 | 6 | 6 | 6300 | 5 | 31/29 | 2370 | 265 | 140 | 4-m12 | 250 | 4-Φ18 | 227287+ 227289 |
201 | ||
| zsw1.3-252/6-3 | 229229 | 6 | 3.5 | 7300 | 5 | 22/21 | 2300 | 280 | 140 | 4-m12 | 254 | 8-Φ18 | 226216+ 227246 |
176 | ||
| zsw1.4-252/6-3 | 229251 | 6 | 6 | 7400 | 5 | 38/36 | 2800 | 260 | 140 | 4-m12 | 250 | 4-Φ22 | 226227+ 227277 |
234 | ||
| zsw1.5-252/6-3 | 229252 | 6 | 6 | 7400 | 5 | 38/36 | 2800 | 260 | 127 | 4-m16 | 270 | 4-Φ18 | 226228+ 227278 |
237 | ||
| zsxw1-252/8-3 | 229257 | 8 | 8 | 6300 | 7 | 30/28 | 2300 | 265 | 140 | 4-m12 | 254 | 8-Φ18 | 227275+ 227292 |
197 | ||
| zsxw1.1-252/8-3 | 229258 | 8 | 8 | 6300 | 6 | 30/28 | 2300 | 265 | 225 | 4-Φ18 | 254 | 8-Φ18 | 228303+ 227291 |
217 | ||
| zsw1-252/8-3 | 229224 | 8 | 3.5 | 6300 | 5 | 22/20 | 2120 | 280 | 140 | 4-m12 | 270 | 4-Φ18 | 227233+ 228231 |
173 | ||
| zsw1.1-252/8-3 | 229287 | 8 | 8 | 6300 | 5 | 30/28 | 2300 | 265 | 140 | 4-m12 | 250 | 8-Φ18 | 227286+ 227324 |
200 | ||
| zsw1.2-252/8-3 | 229267 | 8 | 8 | 6300 | 4 | 30/28 | 2300 | 265 | 225 | 4-Φ18 | 250 | 8-Φ18 | 227283+ 228299 |
215 | ||
| zsw1.3-252/8-3 | 229256 | 8 | 8 | 6300 | 4 | 31/29 | 2400 | 275 | 250 | 4-Φ22 | 286 | 6-Φ18 | 227281+ 228298 |
253 | ||
| zsw1-252/8,5-3 | 229245 | 8.5 | 8 | 6800 | 4 | 34/32 | 2600 | 275 | 225 | 4-Φ18 | 300 | 8-Φ18 | 227273+ 228289 |
267 | ||
| zsw1-252/10-3 | 229216 | 10 | 8 | 6300 | 4 | 22/22 | 2300 | 290 | 225 | 4-Φ18 | 254 | 8-Φ18 | 227216+ 228216 |
223 | ||
| zsw1.1-252/10-3 | 229250 | 10 | 10 | 6300 | 4 | 31/29 | 2400 | 275 | 250 | 4-Φ22 | 280 | 8-Φ18 | 227296+ 228294 |
256 | ||
