Specifications and Parameters:
| Type Designation | SiG-8kW-s | SiG-9kW-s | SiG-10kw-s |
| Input (PV) | |||
| Recommend max, pv input power | 12000Wp | 13500Wp | 15000Wp |
| Max.Pv input voltage | 600V | ||
| Min. operating PV voltage | 40V | ||
| Start-up input voltage | 50V | ||
| Rated PVinput voltage | 360V | ||
| MPPT Voltage Range | 40-560V | ||
| No.of independent MPPT inputs | 3 | ||
| Default No. of PV strings per MPPT | 1 | ||
| Max.PV input current | 16A/16A/16A | ||
| Max.DC short-circuit current | 20A/20A/20A | ||
| output(Ac) | |||
| Max.AC input power from grid | 8000VA | 9000VA | 10000 VA |
| Rated Ac output power | 8000W | 9000W | 10000W |
| Rated AC output current (at 230V) | 34.5A | 39.2A | 43.5A |
| Max. AC output current | 36.5A | 41A | 45.5A |
| Rated AC voltage | 220V/230V/240V | ||
| AC voltage range | 154V~276V | ||
| Rated grid frequency | 50HZ/60HZ | ||
| Grid freguency range | 45~55Hz/55~65Hz | ||
| Harmonic(THD)(at rated power) | <3% | ||
| Power factor at rated power | >0.99 | ||
| Adjustable power factor range | 0.8 leading to 0.8 lagging | ||
| Grid Type | Single phase | ||
| General Data | |||
| Dimensions (W*H*D) | 495*345*180mm | ||
| Weight | ≤19.2kg | ||
| Mounting method | Wall-mounting bracket | ||
| Topology | Transformerless | ||
| Degree of protection | IP65 | ||
| Operating ambient temperature range | -25°C~60°C | ||
| Allowable relative humidity range | 0~100% | ||
| Cooling method | Natural convection | ||
| Max. operating altitude | 4000m | ||
| Display | LED indicator | ||
| Communication | RS485/CAN/WLAN | ||
| DC connection type | MC4 | ||
| AC connection type | Screws & Fasteners | ||
Product Features:
FLEXIBLE APPLICATIONS.
50V extra low start-up voltage
Wider MPPT voltage 40-560V
Incorporate 3 MPpT design
Up to 16A max. Dc input current per MPPT·IV curve online scanning and diagnostics
SAFE & DURABLE
Quick arc fault circuit interrupter (AFCl)
Built-in Type ll DC & AC Surge Protection Devices (SPD)
Multi-level over-temperature derating and protectionSUPERB OFF-GRID LOAD.
Whole-home backup
SMART CONTROL.
24/7 Live monitoring
Remote firmware updates
WLAN,CAN,RS485,4G Available
FRIENDLY DESIGN
≤19.2kg compact design
Fast and easy commissioning via App
Remote troubleshooting and program upgrading
We offer the most advanced engineering design solutions and product technology solutions to global power customers, and continue to create value for the commercial success of global power customers.
