Specifications and Parameters:
| Manufacturer | SieB-H9600-F | SieB-H12K8-F | SieB-H16K0-F | SieB-H19K2-F | SieB-H22K4-F | SieB-H25K6-F | |
| Nominal Energy(kwh) | 9.60 | 12.80 | 16.00 | 19.20 | 22.40 | 25.60 | |
| Usable Energy (kwh)*1 | 9.64 | 11.52 | 14.40 | 17.28 | 20.16 | 23.04 | |
| Module Type | SieB-H3200-F | ||||||
| Module Parameter | 64V 50Ah 615*360*175mm 35kg | ||||||
| Cell Type | LFP (LiFePO4) | ||||||
| Max. Module Configuration | 3 | 4 | 5 | 6 | 7 | 8 | |
| Cell Configuration | 1P60S | 1P80S | 1P100S | 1P120S | 1P140S | 1P160S | |
| Nominal Voltage (V) | 192 | 256 | 320 | 384 | 448 | 512 | |
| Operating Voltage Range (V) | 171~216 | 228~288 | 285~360 | 342~432 | 399~504 | 456~576 | |
| Max. Continuous Current (A)*2 | 30 | ||||||
| Max. Continuous Power(kw)*2 | 5.76 | 7.68 | 9.6 | 17.52 | 13.44 | 15.36 | |
| Communication | CAN/RS485 | ||||||
| Weight (kg) | 120 | 155 | 190 | 225 | 260 | 295 | |
| Dimensions(w*D*H)(mm) | 615*360*730 | 615*360*880 | 615*360*1030 | 615*360*1180 | 615*360*1330 | 615*360*1480 | |
| Operating Temperature (°C) | Charge:0~50/Discharge:-20~50 | ||||||
| Storage Temperature (°C) | -20~45(≤1Months)/-20~25(≤6 Months) | ||||||
| Humidity | 5%~95% | ||||||
| Altitude (m) | ≤2000 | ||||||
| Enclosure Type | IP65 (Indoor /0utdoor) | ||||||
| Cooling | Natural convection | ||||||
| Installation Location | Floor-standing | ||||||
| Display | SOC indicator,Status indicator | ||||||
| Standard andCertification | Safety | IEC 62619 | |||||
| EMC | IEC61000-6-1/3 | ||||||
| Transportation | UN38.3 | ||||||
| Others | RoHS, REACH | ||||||
Product Features:
INSTALLATION FRIENDLY
Easy installation,stackable design with MC4 connectors
Lightweight modules, 35kg per module
P65 protection rating
SAFE & RELIABLE
10 Years warranty & 6000 Cycle life
Dual-laver insulation protection for battery cells and BMS
Unit-level fault isolation
hour salt spray test
FLEXIBLE
Expandable system
Modular scalability
Support 3-8 modules per unit
9.6kwh-25.6kwh
SMART CONTROL
Remote start, software upgrades
Real-time data monitoring
We offer the most advanced engineering design solutions and product technology solutions to global power customers, and continue to create value for the commercial success of global power customers.
